KIA XCEED HATCHBACK

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  8.9
• Battery Charging Scenario 1 - Charge Time (Mins)
  129
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  3.3
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Right Side Rear
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  3.3
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  7
• Usable Battery Capacity
  Not Available
• WLTP - EC (kWh/100km) - Comb
  12.3
• WLTP - EC (miles/kWh) - Comb
  5.1
• WLTP - Equivalent AER (km) - City
  59
• WLTP - Equivalent AER (km) - Comb
  48
• WLTP - Equivalent AER (miles) - City
  36.6
• WLTP - Equivalent AER (miles) - Comb
  29.8

Emissions - ICE

• CO
  0.064
• CO2 (g/km)
  32
• HC
  0.015
• HC+NOx
  Not Available
• Noise Level dB(A)
  67
• NOx
  0.008
• Particles
  0.0001
• Standard Euro Emissions
  EURO 6

Emissions - PHEV

• WLTP - CO2 Weighted (g/km) - Comb
  32

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1580
• Cylinder Layout
  IN-LINE
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO INJECTION
• Gears
  6 SPEED
• Transmission
  SEMI-AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No

Fuel Consumption - PHEV

• WLTP - FC Weighted (l/100km) - Comb
  1.4
• WLTP - FC Weighted (mpg) - Comb
  201.7

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  1.6
• Badge Power
  139
• Based On ID
  Not Available
• Coin Description
  GDi
• Coin Series
  3
• Generation Mark
  3
• Insurance Group 1 - 50 Effective January 07
  12E
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  10000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  7
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  M1

Performance

• 0 to 60 mph (secs)
  10.6
• Engine Power - BHP
  139
• Engine Power - KW
  104
• Engine Power - RPM
  4000
• Engine Torque - LBS.FT
  108
• Engine Torque - MKG
  15
• Engine Torque - NM
  147
• Engine Torque - RPM
  4000
• Top Speed
  99

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  205/60 R16
• Tyre Size Rear
  205/60 R16
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  16" ALLOY

Vehicle Dimensions

• Height
  1478
• Height (including roof rails)
  1483
• Length
  4395
• Wheelbase
  2650
• Width
  1826
• Width (including mirrors)
  Not Available

Weight and Capacities

• Fuel Tank Capacity (Litres)
  37
• Gross Vehicle Weight
  2030
• Luggage Capacity (Seats Down)
  1243
• Luggage Capacity (Seats Up)
  291
• Max. Loading Weight
  436
• Max. Towing Weight - Braked
  1300
• Max. Towing Weight - Unbraked
  600
• Minimum Kerbweight
  1594
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  10.6
